The axial flow fan is efficient for air movement, utilizing a streamlined design that enhances airflow while minimizing energy consumption. This are the backbone of efficient ventilation and air movement across a range of industrial and commercial applications. Available in a variety of sizes, blade configurations, and motor speeds to suit diverse industrial needs. Our axial flow fans are designed to deliver high performance while maintaining low power consumption, reducing operational costs. Ideal for HVAC Systems, Industrial Ventilation, Warehouses and Manufacturing Units, Agricultural and Greenhouse Ventilation and many more.
| Application/Usage | To provide clean air in the room |
|---|---|
| Filter | Cartridge Type, |
| Impeller | Aluminum Casted, |
| MOC | MS Powder Coated, Body MS Fabricated (With both side flanged), High Efficiency Non-FLP Type Motor |
| Duty | Continuous Operation, |
| Power Supply | 3PH, 50 Hz, 440V, |
| Feature | Provision of self-cleaning mechanism for cartridge filter by help of compressed air. |
| Capacity | 2000 CFM |
| Elec. Motor | 0.5 HP & 1425 RPM |
| Capacity | 4000 CFM |
| Elec. Motor | 1 HP & 1425 RPM |
| Capacity | 6000 CFM |
| Elec. Motor | 1.5 HP & 1425 RPM |
Axial Flow Fan (Tube Shaped) Without Filter
| MOC | Body made with G.I. Powder Coated |
|---|---|
| Static pressure | 10 mm WG, |
| Electric Motor (Non-FLP Type) | 1440 RPM & 1.0 / 1.5 HP |
| Duty | S1 (Continuous Operation type) |
| Power Supply | 50 Hz, Three Phase |
| Supply of 2000 CFM Axial Flow Fan (Tube Shaped) | |
| Supply of 4000 CFM Axial Flow Fan (Tube Shaped) | |
| Supply of 6000 CFM Axial Flow Fan (Tube Shaped) |
Axial Flow Fan (Tube Shaped) With Filter
| MOC | Body made with G.I. Powder Coated |
|---|---|
| Static pressure | 10 mm WG, |
| Electric Motor (Non-FLP Type) | 1440 RPM & 1.0 / 1.5 HP |
| Duty | S1 (Continuous Operation type) |
| Pre-Filter | 90% down to 20iµ (EU2 Grade) |
| Power Supply | 50 Hz, Three Phase |
| Supply of 2000 CFM Axial Flow Fan (Tube Shaped) | |
| Supply of 4000 CFM Axial Flow Fan (Tube Shaped) | |
| Supply of 6000 CFM Axial Flow Fan (Tube Shaped) |
