The Mini Pleat HEPA filter machine is designed to provide superior air purification, utilizing advanced mini pleat technology to maximize surface area and enhance filtration efficiency. This compact unit effectively captures 99.997% of airborne particles, including dust, pollen, and pet dander, ensuring a cleaner and healthier indoor environment. Its energy-efficient design and low noise operation make it suitable for both residential and commercial spaces, while the easy-to-replace filter system ensures minimal maintenance and optimal performance.
- Low initial pressure drop
- Resilient
- Wide range of Standard Size
- Double FaceGuard
- Individually tested according to EN 1822
- Guaranteed performance
The Mini-Pleat filters construction shall have extruded anodized aluminum profiles.The Mini-Pleat Panel filters are provided an expanded metal mesh face guards on downstream side and upstream side.
The filter consists of micro-glass fiber media in efficiencies from 99.95% & 99.997% @ MPPS (filter classes according to EN 1822).
| Application | Final or return filtration for clean rooms Laminar air flow for clean benches | |
|---|---|---|
| Type | High efficiency filter panel | |
| Case | Extruded and anodized aluminum. | |
| Media | Micro-FIBRE GLASS | |
| Separator | Hot-melt beads. | |
| Sealant | Polyurethane | |
| Gasket | Neoprene Rubber | |
| FaceGuard | Expanded metal on both side, powder coated | |
| EN 1822 efficiency | H13 / H14 | |
| MPPS efficiency | (H13:>99.95%, H14:> 99.997%) down to 0.3µ | |
| Pressure drop | 120 To 500 Pa. | |
| Temperature | 70° maximum in continuous service. | |
| Humidity | 100% RH | |
| Test | 100% individually tested according to EN 1822 Standard. |
